First
Duo DL

  • Tilting
  • High performance
  • Classic design
  • Reflectors: 10D, 30D, 50D, 20D, 40D, 60D
  • Available Drivers: ON/OFF, Dali, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Installation Type Lumen Maintenance Luminaire Color
220 – 240V PHILIPS – SAMSUNG – CITIZEN 2-Step MacAdam Downlight Power Painted Die-Cast aluminium 50 000h L80 B10 White (RAL 9016),Black (RAL 9005), Silver (Ca. RAL 9006)
COB Type 1208 Forward current System Luminous Flux System Power Lm/W
CRI 90 3000K 2 x 250mA 2 x 1 240 lm 2 x 10,0 W 2 x 124
CRI 90 3000K 2 x 650mA 2 x 3 090 lm 2 x 25,4 W 2 x 121,6
CRI 90 3000K 2 x 1 050mA 2 x 4 736 lm 2 x 41,8 W 2 x 113,3
CRI 90 4000K 2 x 250mA 2 x 1 300 lm 2 x 10,0 W 2 x 130
CRI 90 4000K 2 x 650mA 2 x 3 265 lm 2 x 25,4 W 2 x 128,5
CRI 90 4000K 2 x 1 050mA 2 x 5 030lm 2 x 41,8 W 2 x 120,4
