Casa ULTRA

  • Cost effective in operation
  • Small form factor
  • Reflectors: 15D, 21D, 32D
  • Available Drivers: ON / OFF, Dali, Wireless Masterconnect, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Material Lumen Maintenance Luminaire Color
220-240V PHILIPS- SAMSUNG- CITIZEN 2-Step MacAdam Nordic Aluminium Global Trac Powder Painted Die-Cast Aluminum 50 000h L80 B10 White (RAL 9016), Black (RAL 9005), Silver (ca RAL 9006)
COB Type Forward current System Luminous Flux System Power Lm/W
CRI 90 3000K 200mA 990 lm 8,1 W 122.2
CRI 90 3000K 500mA 2 425 lm 19,4 W 125.0
CRI 90 3000K 650mA 3 090 lm 25,4 W 121.6
CRI 90 4000K 200mA 1 037 lm 8,1 W 128.0
CRI 90 4000K 500mA 2 556 lm 19,4 W 131.7
CRI 90 4000K 650mA 3 265 lm 25,4 W 128.5
