Casa
Duo DL

  • Small formfactor
  • Efficient, up to 135lm/W
  • Tilting
  • Reflectors: 15D, 21D, 32D
  • Available Drivers: ON/OFF, Dali, Casambi

Technical data

Input Power LED-Module Color Consistency Installation Type Installation Type Lumen Maintenance Luminaire Color
220 – 240V PHILIPS – SAMSUNG – CITIZEN 2-Step MacAdam Downlight Power Painted Die-Cast aluminium 50 000h L80 B10 White (RAL 9016),Black (RAL 9005), Silver (Ca. RAL 9006)
COB Type Forward current System Luminous Flux System Power Lm/W
CRI 90 3000K 2 x 250mA 2 x 1 240 lm 2 x 10,0 W 2 x 124
CRI 90 3000K 2 x 650mA 2 x 3 090 lm 2 x 25,4 W 2 x 121,6
CRI 90 3000K 2 x 750mA 2 x 3 519 lm 2 x 29,4 W 2 x 119,7
CRI 90 4000K 2 x 250mA 2 x 1 300 lm 2 x 10,0 W 2 x 130
CRI 90 4000K 2 x 650mA 2 x 3 265 lm 2 x 25,4 W 2 x 128,5
CRI 90 4000K 2 x 750mA 2 x 3 725 lm 2 x 29,4 W 2 x 126,7
