Casa Circle DL
- Small formfactor
- Efficient, up to 135lm/W
- Tilting - Lightweight
- Reflectors: 15D, 21D, 32D
- Available Drivers: ON/OFF, Dali, Casambi
Technical data
| Input Power | LED-Module | Color Consistency | Installation Type | Installation Type | Lumen Maintenance | Luminaire Color |
| 220 – 240V | PHILIPS – SAMSUNG – CITIZEN | 2-Step MacAdam | Downlight | Power Painted Die-Cast aluminium | 50 000h L80 B10 | White (RAL 9016),Black (RAL 9005), Silver (Ca. RAL 9006) |
| COB Type | Forward current | System Luminous Flux | System Power | Lm/W |
| CRI 90 3000K | 250mA | 1 240 lm | 10,0 W | 124.0 |
| CRI 90 3000K | 650mA | 3 090 lm | 25,4 W | 121.6 |
| CRI 90 3000K | 750mA | 3 519 lm | 29,4 W | 119.7 |
| CRI 90 4000K | 250mA | 1 300 lm | 10,0 W | 130.0 |
| CRI 90 4000K | 650mA | 3 265 lm | 25,4 W | 128.5 |
| CRI 90 4000K | 750mA | 3 725 lm | 29,4 W | 126.7 |
